Industrial-Grade MLC 256GB mSATA3.0 SSD Solid State Drive
Industrial-Grade MLC 256GB mSATA3.0 SSD Solid State Drive-UDHO-056
Industrial-Grade MLC 256GB mSATA3.0 SSD Solid State Drive-UDHO-056

Industrial-Grade MLC 256GB mSATA3.0 SSD Solid State Drive

In Stock       1 Year Warranty       EU Free Shipping

PRODUCT CODE: UDHO-056


Industrial-grade MLC 256GB mSATA compact solid state drive with mini PCIe form factor and SATA 6.0Gb/s interface.

Extremely high performance, carries up to 512MB DDR3 cache.

JEDEC MO-300B standard and supports wide operating temperature operation, power failure protection, overvoltage and overcurrent protection.

Excellent stability and durability with high performance and reliable MLC NAND flash memory chips in harsh operating environment such as wide temperature, shock and vibration.

Its excellent stability and durability, can be widely used in various embedded applications.

Features:
Flash management algorithm: static and dynamic wear-leveling, bad block management algorithm
Supports dynamic power management and SMART (Self-Monitoring, Analysis and Reporting Technology)
Supports BCH ECC 66bits in 1KBytes
Support Power Failure Protection
Support over Voltage Protection
Support TRIM
Support NCQ

Specifications:

Basic Information

Capacity

256GB

Form Factor

mSATA

Standard

SATA3.0 , 6Gb/s

Input Voltage

3.3V (±5%)

Size

50.95mm X 30mm X 3.65mm (L x W x H)

Performance

Max Sequential Data Read/Write

550MB/400MB/s

Access Time

<0.1ms

MTBF

>3,000,000 Hours @25C

Data Retention

JESD47 compliant

4Kb Random Read/Write IOPS

70,000 / 75,000

Flash Memory Management

Algorithm

Static and dynamic wear-leveling, bad block management algorithm

Dynamic Power Management

Yes

SMART

Yes

BCH ECC

66bits in 1KBytes

Other Functions

Power Failure Protection

Yes

Over Voltage Protection

Yes

TRIM

Yes

NCQ

Yes

Environment

Operating Temperature

-40°C to +85°C

Storage Temperature

-50°C to +95°C

Humidity

5-95%

Vibration

10Hz-2000Hz, 16.4 G (X, Y, Z axis, 1 hour /axis)

Shock (Peak Acceleration)

1500 G, 0.5ms (Half-sine wave, ±X,±Y,±Z axis, 1 time/axis)

50 G, 11ms (Half-sine wave, ±X,±Y,±Z axis, 3 times/axis)
