Intel® Core™ i7-8565U 2 LAN 10 COM GPIO Three Display Fanless Mini Industrial PC

Product Code: MNHO-082

COMING SOON
  • Datasheet

MNHO-082

Features:

  • Completely Fanless, Silent Mini Industrial PC
  • Intel® Core™ i7-8565U Quad-Core Processor
  • 8 Threads, 8 MB Intel® Smart Cache, up to 4.60 GHz
  • Aluminium Alloy Dustproof
  • Two Intel i211-AT Gigabit RJ45 Ethernet
  • Three HD Display; VGA, HDMI & DVI Display
  • Intel® Iris™ Graphics 540, DirectX 12 OpenGL 4.4, Support 4K HD
  • 12pin 4 Way In/Out GPIO Phoenix Terminal
  • 10 x RS232 DB9 COM Ports
  • Support WiFi/3G/4G LTE (optional)
  • Support up to 32GB SODIMM DDR4 Memory
  • Support Three Storage (mSATA & 2.5" SATA SSD/HDD & M.2 2280 NVMe SSD)
  • Four USB 3.0 & Three USB 2.0 Ports
  • Intel® AES-NI Data Protection
  • Energy Efficient, Low Power Consumption
  • Support Windows 10 & Linux etc.
  • Perfect for Industrial Automation, Manufacturing Process, Displays, Stations
    and Training Applications etc.


Specifications:

Processor
Intel® Core™ i7-8565U Processor
4 Core, 8 Threads
8 MB Intel® Smart Cache, up to 4.60 GHz

Memory
Support up to 32GB
SODIMM DDR4 2133/2400MHz
non-ECC Memory
Two Memory Slots

Storage
Support 1 x mSATA SSD
Support 1 x 2.5" SATA SSD/HDD
Support 1 x M.2 2260/2280 NVMe SSD

Display
Three Display
VGA, HDMI & DVI-I
Intel® Iris™ Graphics 540
Support DirectX 12 OpenGL 4.4
Support 4K HD

Expansion Slots
1 x mSATA (For mSATA SSD)
1 x Full Size mini PCIe (For WiFi/4G Module)
1 x M.2 2260/2280 NVMe
1 x 2.5" SATA Slot (For 2.5" SSD/HDD)

OS
Support Windows 10
Support Linux

Front I/O Interfaces
2 x Intel i211-AT Gigabit LAN (Support Network
Wake-up/PXE)
8 x RS232 DB9 COM
1 x HDMI
1 x VGA
1 x DVI-I
4 x USB 3.0
1 x PS/2 (Mouse & Keyboard)
1 x DC 9~36V In 1 (3pin Terminal Block)
1 x DC 9~36V In 2
1 x Audio In & Out (ALC662 6-Channel HD)
2 x Antenna Ports

Rear I/O Interfaces
2 x RS232 DB9 COM
3 x USB 2.0
1 x SIM Slot
1 x 12pin 4 Way In/Out GPIO Phoenix Terminal
1 x Reset Switch
1 x Power Switch
1 x HDD LED, 1 x Power LED
1 x AC Loss Power on Switch

CPU Advanced Technologies
Intel® Speed Shift Technology
Intel® Thermal Velocity Boost
Intel® Hyper-Threading Technology
Intel® Virtualization Technology
Enhanced Intel SpeedStep® Technology
Intel® Identity Protection Technology
Intel® Smart Response Technology
Intel® AES New Instructions

Onboard I/O
1 x mSATA Slot
1 x Mini PCIe Slot
1 x 2.5" SATA Slot
1 x M.2 2260/2280
1 x PCIE x16 Slot
2 x SODIMM DDR4
1 x USB2.0 Port
1 x 4pin ATX Power In
1 x 4pin CPU Fan Interface

Power & Working Environment
Power Type: External Power Adapter
Power Adapter Input: AC 100-240V ~ 50-60Hz
Power Adapter Output: DC 12V 5A
System Power Input: DC 9V~36V
Operating Temperature: -10°C ~ 40°C
Storage Temperature: -20°C ~ 70°C
Relative Humidity: 5% - 95% relative humidity (noncondensing)
Vibration: 0.5g rms/5-500HZ/random/operating

Others
BIOS: 64Mb Flash ROM
Watchdog: Support (L256 Segments, 0~255 Sec.)
Weight: 2.5KG
Cooling: Aluminium Alloy FANLESS, Silent
