Intel N5105 4 LAN 2.5GbE 5G CPE Fanless Network Appliance SD-WAN Security Gateway with TPM
Intel N5105 4 LAN 2.5GbE 5G CPE Fanless Network Appliance SD-WAN Security Gateway with TPM-MNHO-095
Intel N5105 4 LAN 2.5GbE 5G CPE Fanless Network Appliance SD-WAN Security Gateway with TPM-MNHO-095
Intel N5105 4 LAN 2.5GbE 5G CPE Fanless Network Appliance SD-WAN Security Gateway with TPM-MNHO-095

Intel N5105 4 LAN 2.5GbE 5G CPE Fanless Network Appliance SD-WAN Security Gateway with TPM

In Stock       1 Year Warranty       UK Free Shipping

PRODUCT CODE: MNHO-095

Intel N5105 4 LAN 2.5GbE 5G CPE Fanless Network Appliance SD-WAN Security Gateway with TPM - MNHO-095 | Image
PICO PC® 4 LAN network appliance powered by the latest 11th Gen. Intel "Jasper Lake" quad-core N5105 processor up to 2.90 GHz with Intel® AES-NI for secure and fast data encryption and decryption. A complete network hub as a VPN, suitable for building firewall/router/security gateway, network-based applications in client/server environments. Best for 5G CPE and SDWAN.

Integrated trusted platform module (TPM 2.0) to secure hardware with integrated cryptographic keys and provide security against threats like firmware and ransomware attacks. Aluminium alloy dustproof FANLESS structure with copper heat-pipe cooling solution. Energy-efficient design that reduces environmental impact, works noiseless with fewer moving parts and less maintenance.

Support wireless networks 802.11 AC/AX Wi-Fi 6 (up to 2.4Gbps) as well as 4G LTE/5G WWAN networks (optional) with dual micro-SIM connectivity. Support up to 16GB SODIMM DDR4 non-ECC memory and dual storage drives including mSATA SSD and 2.5" SATA SSD/HDD. Comprehensive connectivity with multiple ports, including a USB 3.1/USB2.0, HDMI HD display port powered by integrated Intel UHD Graphics and multiple network connections, 4x Intel i226-V 2.5Gig RJ45 Ethernet ports (supports network wake-up/PXE) and RJ45 console port for networking and communication tasks.

High performance & perfect for VPN, DNS Server, DHCP Server, network bandwidth controller, network servers, LAN or WAN router, firewall and UTM applications to deliver a high throughput, reliable operation and wide array of network applications, network servers, Linux, Unix, Windows 10/11/server, Proxmox Virtual Environment (VE), firewalls (either open-source or commercial) and gateways. You can add multiple LAN's or multiple WLAN's to your network, each segmented for maximum security and configurability. It combines a robust industrial-grade performance and the advantages of network security management, can be widely used in virtual private networks, traffic control, network firewalls or other network applications.


Features:

Fanless Firewall, Security Gateway Network Appliance
11th Gen. Intel N5105 Quad-Core Processor up to 2.90 GHz
Aluminum Alloy Dustproof Fanless with Heat-pipe Solution
4x Intel i226-V 2.5Gig RJ45 Ethernet Ports (Network wake-up/PXE)
Integrated Trusted Platform Module (TPM 2.0)
HDMI Display, Support 4K HD (Intel UHD Graphics)
RJ45 Console, USB 3.1/USB 2.0 Ports
Support 802.11 AC/AX Wi-Fi Network
Support WWAN 5G/4G LTE Networks with Dual SIM
Support up to 16GB SODIMM DDR4 Memory
Support Dual Storage (mSATA & 2.5" SATA SSD/HDD)
Intel® AES-NI Data Protection
Energy Efficient, Low Power Consumption
Easy Installation & VESA Mounting Capabilities
Support Windows 10/11/Server & Linux, Firewalls etc.
Can be configured as a Firewall, LAN/WAN Router, VPN, DNS Server, DHCP Server
Perfect for 5G CPE, SDWAN, Security Gateway, Server, VPN and Firewalls.

Specifications:

System

Model

PICO PC® MNHO-095

Part Number (P/N)

MO95N51ND4L1C

Processor

CPU

Intel® Celeron® Processor N Series N5105

Processor Base Frequency

2.90 GHz

TDP

10W

# of Cores

4

# of Threads

4

Cache

4 MB L3

Memory

Size

Support up to 16GB (optional)

Type

SODIMM DDR4 (non-ECC)

Slot

1

Storage

mSATA

Support 1 x mSATA SSD (optional)

2.5" SATA

Support 1 x 2.5" SATA SSD/HDD (optional)

eMMC

up to 128GB (optional)

Expansion Slots

mSATA

1 x mSATA 3.0 (For mSATA SSD)

Mini PCIe

1 x Half Size mini PCIe (For WiFi/BT Module)

M.2 3042/3052

1 x M.2 3042/3052 B-Keyed (For 4G/5G Module)


CPU Advanced Technologies

Intel® Speed Shift Technology

Yes

Intel® 64

Yes

Enhanced Intel SpeedStep® Technology

Yes

Thermal Monitoring Technologies

Yes

Intel® Identity Protection Technology

Yes

Intel® AES New Instructions

Yes

Intel® OS Guard

Yes

Intel® Boot Guard

Yes

Intel® Virtualization Technology (VT-x)

Yes

Intel® Virtualization Technology for Directed I/O (VT-d)

Yes

Intel® VT-x with Extended Page Tables (EPT)

Yes

I/O Interfaces

LAN

4x Intel I226-V 2.5Gig Ethernet

COM

1 x RJ45 Console

Display

1 x HDMI

USB

1 x USB 3.1

1 x USB 2.0

DC-In

1 x DC 12V~22V In (Screw Locking Jack)

SIM

2 x Micro-SIM Slot

Antenna

6 x Antenna Ports

Switch

1 x Reset Switch

1 x Power Switch

LED Indicator

1 x HDD LED

1 x Power LED

OS

Windows

Support Windows 10/11/Server

Linux

Support

Firewalls

Support OPNsense. (not included)

Power Adapter

Input

AC 100-240V ~ 50-60Hz

Output

DC 12V~22V 5A

Safety & EMC

UL, CE, FCC, RoHS

EMC EN55022 CLASS B

IEC 60950-1

Energy saving standards

Energy Star Ver. 2.0

DOE Level VI

ErP CoC Version 5 Tier 2

Working Environment

Operating Temperature

0°C ~ 40°C

Compliance

Approvals

CE, FCC & RoHS, UKCA

Others

Cooling

Aluminium Alloy FANLESS, Silent

Size

163 x 109 x 35 mm (L*W*H)

Package

1 x Mini PC

1 x Power Adapter

1 x Power Cord

1 x SATA Cable

Intel N5105 4 LAN 2.5GbE 5G CPE Fanless Network Appliance SD-WAN Security Gateway with TPM - MNHO-095 | ImageIntel N5105 4 LAN 2.5GbE 5G CPE Fanless Network Appliance SD-WAN Security Gateway with TPM - MNHO-095 | ImageIntel N5105 4 LAN 2.5GbE 5G CPE Fanless Network Appliance SD-WAN Security Gateway with TPM - MNHO-095 | Image

Download Datasheet - MNHO-095 | Image

This section describes the real-world performance with respect to different firewalls; showing details below. This will outline the technical specification & configurations required by a firewall administrator to operate and troubleshoot the hardware/software properly.


OPNsense Hardware Performance

Total Firewall Throughput

Firewall Throughput

4.40 Gbps

IPS Throughput

1.5 Gbps

Number of Users

800-1600



Firewall Sessions

Concurrent Sessions (TCP)

0.76 Million

New Sessions/Second (TCP)

23,500

IPSec VPN Peers

600



IPSec VPN Tunnel Throughput

IPSec VPN (TCP)  AES-128

900 Mbps

IPSec VPN (TCP)  AES-256

860 Mbps

IPSec VPN (UDP)  AES-128

945 Mbps

IPSec VPN (UDP)  AES-256

900 Mbps

OPEN VPN Throughput

OPEN VPN (TCP) AES-256 Remote Access

440 Mbps

OPEN VPN (UDP) AES-256 Remote Access

850 Mbps

OPEN VPN  (TCP) AES-256 end-to-end

375 Mbps

OPEN VPN  (UDP) AES-256 end-to-end

720 Mbps

Bridge Mode Throughput

L2 (TCP)

2.25 Gbps

L2 (UDP)

2.30 Gbps

NAT Mode Throughput

L3 (TCP)

2.10 Gbps

L3 (UDP)

2.20 Gbps

Routed Mode Throughput

L3 (TCP)

2.18 Gbps

L3 (UDP)

2.25 Gbps
