The AMD Ryzen™ 7 7800X3D is a high-performance desktop processor designed to deliver exceptional computational power and efficiency, especially for gaming and demanding applications. It is built on the cutting-edge Zen 4 architecture and utilizes AMD's advanced 3D V-Cache™ technology, which significantly increases the amount of L3 cache available to the processor, enhancing gaming performance and reducing latency.
Featuring eight cores and sixteen threads, the Ryzen 7 7800X3D excels in multi-threaded performance, making it well-suited for intensive tasks such as gaming, content creation, and multitasking. It operates at a base clock speed of 4.2 GHz, with the ability to boost up to 5.0 GHz, ensuring rapid and responsive processing for both single-threaded and multi-threaded workloads. One of the key features of the Ryzen 7 7800X3D is its support for PCIe 5.0, which provides significant improvements in data transfer rates, crucial for the latest high-speed storage solutions and next-generation graphics cards.
Additionally, the processor supports DDR5 memory, offering higher bandwidth and improved efficiency compared to DDR4, which enhances overall system performance and multitasking capabilities. With a Thermal Design Power (TDP) of 120 watts, the Ryzen 7 7800X3D delivers a powerful performance while requiring robust cooling solutions to maintain optimal operating temperatures. It includes integrated AMD Radeon™ Graphics, featuring 2 graphics cores with a frequency of 2200 MHz. It supports USB Type-C® DisplayPort™ Alternate Mode, providing additional connectivity options.
Advanced features such as AMD Precision Boost 2 dynamically adjust the processor's clock speeds to optimize performance based on current thermal and power conditions. Precision Boost Overdrive allows for automatic overclocking when additional thermal headroom is available, giving users the ability to further push the processor’s performance. The processor also includes support for Curve Optimizer, which allows for fine-tuning of voltage settings for each core, optimizing both performance and power consumption. AMD EXPO™ (Extended Profiles for Overclocking) Memory Overclocking Technology is supported as well, simplifying the process of memory overclocking with predefined profiles to enhance overall system performance. Supported by AMD Ryzen™ Master, a comprehensive utility for monitoring and tuning the processor's performance, users can easily customize clock speeds, voltages, and memory timings to create optimized performance profiles for different applications.
Features:
AMD Ryzen™ 7 7800X3DAM5 Processor
8 CPU Cores and 16 Threads
Max. Boost Clock up to 5 GHz and Base Clock 4.2 GHz.
PCIe® 5.0 Interface
Supports DDR5 Memory Type
Supports 2 Memory Channels
Default TDP is 120W
AMD Radeon™ Graphics Model
2 x Graphics Core Count
2200 MHz Graphics Frequency
Maximum Operating Temperature is 89°C
4 x Native USB 3.2 Gen 2 (10Gbps) Ports support
1 x Native USB 2.0 (480Mbps) Ports support
AMD EXPO™ Memory Overclocking Technology, Precision Boost Overdrive, Curve Optimizer Voltage Offsets, and AMD Ryzen™ Master Support are supported
Specifications:
General Specifications | Name | AMD Ryzen™ 7 7800X3D |
Family | Ryzen |
Series | Ryzen 7000 Series |
Product ID | 100-100000910WOF |
Form factor | Desktops , Boxed Processor |
Architecture | Zen 4 |
CPU Cores | 8 |
Threads | 16 |
Max. Boost Clock | Up to 5 GHz |
Base Clock | 4.2 GHz |
L1 Cache | 512 KB |
L2 Cache | 8 MB |
L3 Cache | 96 MB |
Default TDP | 120W |
Processor Technology(CPU Cores) | TSMC 5nm FinFET |
Processor Technology for I/O Die | TSMC 6nm FinFET |
CPU Compute Die (CCD) Size | 71mm² |
I/O Die (IOD) Size | 122mm² |
CPU Socket | AM5 |
Supporting Chipsets | A620 , X670E , X670 , B650E , B650 |
CPU Boost Technology | Precision Boost 2 |
Instruction Set | x86-64 |
Supported Extensions | AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 |
Thermal Solution | Liquid cooler recommended for optimal performance |
Max.Operating Temperature | 89°C |
Launch Date | 06/04/2023 |
OS Support | Windows 11/ 10 - 64-Bit, RHEL x86 64-Bit , Ubuntu x86 64-Bit |
Connectivity | PCI Express Version | PCIe® 5.0 |
Native PCIe® Lanes (Total/Usable) | 28 , 24 |
Additional Usable PCIe Lanes
from Motherboard | X670E 12x Gen4 |
X670 12x Gen4 |
B650E 8x Gen4 |
B650 8x Gen4 |
Native USB 3.2 Gen 2 (10Gbps) Ports | 4 |
Native USB 2.0 (480Mbps) Ports | 1 |
NVMe Support | Boot , RAID0 , RAID1 , RAID10 |
System Memory Type | DDR5 |
Memory Channels | 2 |
Max. Memory | 128 GB |
System Memory Subtype | UDIMM |
Max Memory Speed | 2x1R DDR5-5200 |
2x2R DDR5-5200 |
4x1R DDR5-3600 |
4x2R DDR5-3600 |
ECC Support | Yes (Requires mobo support) |
Graphical Capability | Graphics Model | AMD Radeon™ Graphics |
Graphics Core Count | 2 |
Graphics Frequency | 2200 MHz |
USB Type-C® DisplayPort™
Alternate Mode | Yes |
Technology | Supported Technologies | AMD EXPO™ Memory Overclocking Technology,
Precision Boost Overdrive ,
Curve Optimizer Voltage Offsets,
AMD Ryzen™ Master Support, AMD EXPO™ Technology, AMD Ryzen™ Technologies |
In Stock
