PRODUCT CODE: GPHO-076
The MSI GeForce RTX 5080 GAMING TRIO OC is engineered for enthusiasts seeking exceptional performance in gaming and content creation. Built on NVIDIA's advanced Blackwell architecture, it features 10752 CUDA cores and 16GB of high-speed GDDR7 memory with a 256-bit memory bus, delivering a memory speed of 30 Gbps. The card supports DLSS 4 for AI-enhanced graphics and NVIDIA Reflex 2 for ultra-responsive gameplay.
Cooling is managed by MSI's TRI FROZR 4 system, which includes STORMFORCE fans with claw-textured blades and a circular arc design, a nickel-plated copper baseplate, and Wave Curved 4.0 fins for optimal airflow and heat dissipation. The card offers versatile connectivity with three DisplayPort 2.1b ports and one HDMI 2.1b port, supporting up to 8K resolution. With a boost clock of up to 2715 MHz in Extreme Performance mode, the RTX 5080 GAMING TRIO OC is a powerhouse for any demanding application.
Key Features:
Powered by NVIDIA Blackwell architecture for advanced gaming and creative performance
Equipped with 10752 CUDA cores and 16GB GDDR7 memory for high-speed processing
Supports DLSS 4 and NVIDIA Reflex 2 for AI-enhanced graphics and low-latency gaming
Features TRI FROZR 4 cooling system with STORMFORCE fans and Wave Curved 4.0 fins
Offers connectivity with 3x DisplayPort 2.1b and 1x HDMI 2.1b, supporting up to 8K resolution
Boost clock speeds up to 2715 MHz in Extreme Performance mode
Requires a single 16-pin PCIe power connector and an 850W recommended PSU
Dimensions: 338 x 140 x 50 mm; triple-slot design
Supports DirectX 12 Ultimate and OpenGL 4.6 for broad compatibility
Backed by a 3-year limited warranty for peace of mind
Specifications:
MPN | RTX 5090 32G GAMING TRIO OC |
GPU Model | NVIDIA GeForce RTX 5080 |
CUDA Cores | 10,752 |
Architecture | Blackwell |
Base Clock | 2,295 MHz |
Boost Clock | 2,700 MHz (GAMING & SILENT Mode), 2,715 MHz (Extreme Performance Mode) |
Memory Size | 16 GB GDDR7 |
Memory Speed | 30 Gbps |
Memory Bus | 256-bit |
Memory Bandwidth | 960 GB/s |
Interface | PCI Express 5.0 x16 |
Outputs | 3 x DisplayPort 2.1b, 1 x HDMI 2.1b |
Maximum Resolution | 7680 x 4320 (8K UHD) |
Maximum Displays Supported | 4 |
DirectX Support | DirectX 12 Ultimate |
OpenGL Support | OpenGL 4.6 |
HDCP Support | Yes (HDCP 2.3) |
VR Ready | Yes |
Cooling System | TRI FROZR 4 with STORMFORCE fans |
Power Consumption | 360 W |
Power Connector | 1 x 16-pin PCIe |
Recommended PSU | 850 W |
Card Dimensions (L x W x H) | 338 x 140 x 50 mm |
Slot Width | Triple-slot |
Warranty | 3 Years Limited |
